Available Addons
Van Bodies
Service Body,
Flatbed Body,
Curtain Sider
(All of these option are addons and must be special ordered)
Cab Colors
Colors
Arc White,
Cardinal Red,
Wheatland Yellow,
Dark Blue,
Woodland Green,
Ebony Black
(All models are available immediately in white. Other colors shown may be special-ordered at no-extra charge.)
Weight Ratings
GVWR/GCWR
15,500 lb./20,500 lb.
GAWR (front/rear)
5,360 lb./9,880 lb.
Body/Payload
Estimated Max
8,564 lb.
Engine
Model
Isuzu 4HK1-TC
Type
Turbocharged intercooled diesel, 4 cylinder
Displacement
317 cu. in. (5.2 L)
Max Output
215 hp @ 2,500 rpm
Max torque
452 lb.-ft. @ 1,850 rpm
Transmission
Standard
Aisin A460 6-speed auto, with double overdrive and lock-up 2nd-6th gears
Axles
Front/Rear
6,830 lb./11,020 lb.
Suspension
Front and Rear
Tapered/Multi-Leaf
Brakes
Service
Vacuum/Hydraulic with 4-Channel ABC Disc/Drum
Frame
Section Modulus
7.20cu. in. per rail
Resistance Bending Moment
316,800 lb.-in.
